SHJZ-2000VA(copper)
ShunHong
TW20001
Availability: | |
---|---|
Quantity: | |
Product Advantage
After more than 20 years of technological innovation and market validation, our transformers have become industry leaders for their superior stability and durability. This transformer shows excellent performance in voltage adaptation, and can accurately convert the voltage from 220V to 240V to 110V without loss, greatly expanding the use range and compatibility of electrical appliances.
In materials and processes, we constantly strive for excellence, using advanced single-phase ring inner core manufacturing technology. This innovation not only reduces energy loss, but also improves conversion efficiency, ensuring that the equipment can maintain high performance and stability even during long-term operation.
Safety is the focus of our design. The transformer uses a strong iron shell construction, combined with the use of flame retardant materials and built-in temperature control protection devices, to provide users with comprehensive security. These carefully designed measures give users complete peace of mind during use without worrying about any safety issues.
Technical Parameters
Product Model | SHJZ-2000VA(copper) |
Product name | Copper 2000W Temperature Control Protection Voltage Converter 220V to 110V |
Maximum applicable power | 2000W* |
Rated Input Voltage | 220V~ |
Rated output voltage | 110V~ |
Rated capacity | 1400VA* |
Rated Frequency | 50/60Hz |
Operating cycle | 30/60min |
sizes | 20*16*9.5cm |
Size (with package) | 30*20*15cm |
weights | 6.4kg |
Weight (with package) | 6.8kg |
Type | Dry-type |
Safety Device-1 | Temperature Control |
Automatic power-off temperature | ≥80℃ |
Power cord square | 1 square |
Maximum Passing Current | 8A |
Materials | Aluminum wire winding |
Core material | Ring transformer |
certificate | CE、FCC Etc. |
Product Uses
With the increasing popularity of electrification today, voltage converters have become a key device in our daily lives. This article will introduce a new 2000W transformer, which not only has high efficiency and stability, but also can adapt to diverse power needs, providing you with a full range of voltage conversion solutions.
High efficiency design, wide applicability
With its powerful power of 2000W and the conversion ability of 220V to 110V, this transformer provides an ideal voltage conversion solution for all kinds of electrical appliances. Whether it is a home, office, beauty salon or medical environment, it provides stable and reliable power support.
Ideal for home appliances
No matter where you are, as long as the local voltage is 220V, this transformer can ensure the safe operation of your household appliances. It supports a power output of up to 800W and reserves 20% of the power space to ensure the safety and stability of use. Whether it's a lamp, an air purifier or a dental cleaner, you can enjoy a worry-free electricity experience anywhere in the world.
The best partner for office equipment
In the office space, this transformer can provide a stable and reliable voltage output for office equipment requiring 110V voltage. Whether it is a small printer, copier or scanner, you can ensure the efficient operation of equipment, avoid voltage mismatch caused by equipment damage and performance degradation, significantly improve office efficiency.
A professional partner in the beauty and hair industry
For users who pursue high-quality life, this transformer also performs well. It can easily adapt to a variety of beauty salon equipment, such as home curling iron, face steam and RF beauty instrument, simple operation can achieve voltage conversion, so that you can also enjoy professional level beauty salon services at home.
Security of medical equipment
For those users who rely on home medical equipment, this transformer provides a stable 110V voltage output, ensuring the stable operation of domestic small pressure gauges, small oxygen generators and other medical equipment imported from North America, providing a solid guarantee for your healthy life.
Product Operate Guide
In the age of electrification, voltage converters have become indispensable tools for us. To ensure their safe use, we have provided a new safety guide to guide you in the proper use and maintenance of voltage converters.
Keep away from moisture and dry
The voltage converter will generate heat during operation, and should be avoided in the vicinity of wet or water sources to prevent electrical short circuit and equipment corrosion. Choosing a dry, ventilated environment to place the converter helps maintain its performance and extend its service life.
Keep the heat sink unblocked
Regularly clean the heat dissipation hole of the converter to prevent dust and debris blockage, ensure smooth heat dissipation, and avoid performance degradation or damage caused by overheating.
Thorough inspection before first use
Before first use, the voltage converter is thoroughly inspected to ensure that there are no damage, cracks or abnormal marks. After the power is turned on, pay attention to whether there is abnormal sound or state, power off immediately and contact professionals.
Connect correctly and follow the operating procedures
Follow the instructions provided by the manufacturer to properly connect the power supply and electrical equipment to ensure that the connection is secure and avoid loose or poor contact.
Regular maintenance and inspection
In order to ensure long-term stable operation, regular maintenance and inspection of the voltage converter, including checking the integrity of the power cord, plug and the performance status of the converter.
Use protection
When the converter is working, use appropriate protection measures such as overload protector and leakage protector to improve the safety of use.
Close the program correctly
After use, turn off the voltage converter according to the correct procedure, disconnect the electrical equipment first, and then disconnect the power supply to avoid electrical shock.
Power transformer is an indispensable component in the electrical system, and its correct operation is not only related to the safety of the equipment, but also directly affects the operating efficiency of the system. Here is a comprehensive guide on how to use power transformers safely and efficiently.
Step 1: Appearance check and parts confirmation
Before starting a power transformer, a comprehensive visual inspection is the first step. Ensuring that the transformer housing is intact and that all parts and screws are secured in place is the basis for preventing electrical failure and maintaining the integrity of the equipment.
Step 2: Connect the power supply correctly
Plug the input plug of the transformer into a 220V power outlet that matches the rated input voltage of the transformer. Before connecting the power supply, ensure that the voltage of the socket meets the requirements of the transformer to avoid device damage caused by voltage mismatch.
Step 3: Start the transformer carefully
Locate the power switch of the transformer and gently press it to turn on the power. During the startup process, pay attention to whether there are abnormal sounds or vibrations, which may be an early signal of equipment problems. If all is well, the transformer's indicator light will light up, indicating that the device has been successfully powered on.
Step 4: Securely connect electrical equipment
Securely connect electrical equipment requiring 110V voltage to the output port of the transformer. When connecting, ensure that the electrical power does not exceed the maximum carrying capacity of the transformer to prevent overload. After the connection is complete, turn on the electrical power supply, and the electrical appliance should be able to start and run normally.
Step 5: Monitor the operating status
Periodically monitor the operating status of transformers and electrical equipment during their operation. Pay attention to whether the transformer is overheating, whether the electrical appliances are running smoothly, to ensure the safety and stability of the entire system.
Step 6: Turn off the device correctly
After use, turn off the power in the correct order. First turn off the power switch of the electrical equipment, then turn off the power of the transformer, and finally pull out the input plug to ensure that the electrical system is safely shut down.
Step 7: Regular maintenance and inspection
In order to ensure the long-term stable operation of the transformer, regular maintenance and inspection are necessary. This includes cleaning the transformer, checking the integrity of the power cords and plugs, and monitoring the performance status of the transformer.
FAQ
Product certification and safety assurance
We are proud to announce that our voltage converters have received international and national certifications such as CE, ROHS and FCC, which ensure that products meet high standards in electrical safety, environmental protection and electromagnetic compatibility, providing you with an additional level of security.
Perfect after-sales service
We understand the importance of after-sales service and provide comprehensive after-sales support, including product consultation, user guidance and breakdown repair services. Our customer service team is always on hand to answer your questions and provide the necessary technical support. We also provide a certain period of warranty service to ensure that your use of the experience.
Select the right voltage converter
When choosing a voltage converter, first consider the rated voltage and power of the appliance to ensure that the output voltage and power of the selected transformer match your appliance. At the same time, considering the frequency and length of use of the appliance, choose a transformer that can provide stable power output. Finally, consider the brand, quality and price, choose cost-effective and safe and reliable products.
Preparation before use
Before purchasing a voltage converter, understand the rated voltage and power of the appliance, and confirm the power supply voltage in the area to ensure that the transformer can work normally. Consider the use of the environment and frequency, choose the appropriate transformer type and brand. Understand the brand and price information in the market to help you make informed purchasing decisions.
Instructions for the use of specific appliances
Our voltage converter is suitable for electrical appliances below 1200W, but for electrical appliances with motors and heating, it is recommended to choose the appropriate transformer according to the electrical power. For example, high power devices such as hair dryers may require higher power transformers.
Voltage ratio and power selection
Choose the right voltage converter based on the voltage standards in your area and the voltage requirements of your appliances. For example, when using American appliances, European users choose 220V to 110V, and vice versa, 110V to 220V. When Chinese users use Japanese electrical appliances, they choose 220V to 100V. In the purchase, taking into account the loss of the transformer, it is recommended to choose a transformer greater than 20% of the electrical power.
Find appliance power
The power of an appliance can usually be found on the device itself, on the bottom, or in the manual. This is an important reference when choosing a voltage converter.
