SHJZ-2000VA
ShunHong
W20002
Availability: | |
---|---|
Quantity: | |
Product Advantage
Technical Parameters
Product Model | SHJZ-1000VA |
Product name | 2000W Temperature Control Protection Voltage Converter 110V to 220V |
Maximum applicable power | 2000W* |
Rated Input Voltage | 110V~ |
Rated output voltage | 220V~ |
Rated capacity | 1200VA* |
Rated Frequency | 50/60Hz |
Operating cycle | 30/60min |
sizes | 20*16*9.5cm |
Size (with package) | 30*20*15cm |
weights | 5.6kg |
Weight (with package) | 6.0kg |
Type | Dry-type |
Safety Device-1 | Temperature Control |
Automatic power-off temperature | ≥80℃ |
Power cord square | 1 square |
Maximum Passing Current | 8A |
Materials | Aluminum wire winding |
Core material | Ring transformer |
certificate | CE、FCC Etc. |
Product Uses
Product Operate Guide
Securely connect electrical equipment requiring 110V voltage to the output port of the voltage converter. When connecting, ensure that the power of the appliance is within the maximum load range of the converter to avoid the risk of overload. After the connection is complete, turn on the electrical power and enjoy a stable and safe power supply.
"Easy Operation Manual for Voltage converters: A four-step process with stable power at your fingertips"
Voltage converters are a convenient tool for power adaptation in modern life, and the following is a simple guide to help you enjoy stable power easily.
Step 1: Thoroughly check the device and connection
Before starting to use a voltage converter, it is important to thoroughly inspect the equipment and all its accessories. Verify that the converter housing, plugs, and cables are intact and that all accessories are complete and in good condition. This step is key to preventing electrical failures and ensuring the proper operation of the equipment.
Step 2: Connect 220V power correctly
Plug the input plug of the voltage converter into the 220V power outlet. Before connecting, double-check that the socket voltage matches the input voltage requirements of the converter to prevent damage to the device caused by voltage mismatch.
Step 3: Start the voltage converter
Locate the power switch on the converter and tap to start the device. When starting up, watch closely for any unusual reactions, such as unusual sounds or unlit lights, which may be an early sign that there is a problem with the device.
Step 4: Securely connect and use 110V appliances
Securely connect electrical equipment requiring 110V voltage to the output port of the voltage converter. When connecting, ensure that the power of the appliance does not exceed the maximum carrying capacity of the converter to avoid overload. Once the connection is complete, turn on the power switch of the appliance and enjoy a stable and safe power supply.
By following this four-step guide, you can ensure the safe and efficient use of your voltage converter to ensure the normal operation of your electrical equipment and the stability of your power supply, wherever and whenever you need it.
FAQ
